Model:

AC-300ST

AC-300PT

Image Sensor :

1/4” SHARP CCD

1/3” SONY Super HAD CCD

Effective Pixels :

PAL:500(H)*582(V)

NTSC: 510(H)*492(V)

PAL:500(H)*582(V)

NTSC: 510(H)*492(V)

Sensing Area :

3.6mm*2.7mm

4.9mm*3.7mm

Signal System:

PAL/NTSC

Horizontal Resolution:

420TV Line

420TV Line

Lens Mount:

3.6mm.6mm.8mm.12mm Selectable

Mini Illumination:

0 Lux/F1.2

0 Lux/F1.2

Back Light Compensation:

Built-in

Shutter Speed:

1/50—1/100,000 second

White Balance :

Auto Tracking White Balance

S/N Ratio:

more than 48dB (AGC OFF)

Video Output:

1.0Vp-p.75Ω(BNC)

Power Supply:

DC12V/500mA

Power Consumption:

Less than 2.8W

Infrared Wavelength:

850mm

Infrared Lamps Irradiation Distance:

20M

Infrared Lamps:

Night/Day Opeing/Turn Off

Illumination for Infrared Turn On:

>3.0 Lux

Video Out :

VIDEO OUT (BNC)

Dimension/mm:

￠128mm*106mm

Weight(g):

220g
